EQUIPMENT

NTEGRA SPECTRA II.jpg

NTEGRA SPECTRA II – VERSATILE AUTOMATED AFM-Raman, SNOM AND TERS SYSTEM

​

  • High-performance versatile AFM

  • Automated AFM laser, probe and photodiode alignment

  • Integration with IR s-SNOM

  • Investigation of graphene, carbon nanotubes and other carbon materials; semiconductor devices; cellular tissue, DNA, viruses and other biological objects

  • Optical device characterization: semiconductor lasers, optical fibers, waveguides, plasmonic devices



CNC LaserGRBL Engraving Machine

​

  • Laser power: 100-4500 mW

  • Laser wavelength: 450 nm

  • Continuous diode laser

  • Large scale engraving area

  • Bulilt-in firmware: GRBL 1.1f

  • Frame Material: Aluminum and Acrylic

  • Power Supply: DC12V 5A, Input 100V-240V AC,50/60Hz

  • Stepper motor driver: Integrated A4988

  • Engraving speed: 100-5000m/min

  • Cutting speed: 1-100ms/pixels

DIY Mini USB Laser Engraving Machine

​

  • Multifunctional portable laser engraving machine

  • Main material: ABS

  • Input voltage: AC 100-240V

  • Output: 12V 2A

  • Laser power: 3000mW

  • Laser wavelength: 450nm

  • Continuous diode laser

  • Carving accuracy: 0.05mm

  • Engraving object size: no limit

AFM NTEGRA NT-MDT system

​

  • Capability performing more than 40 measuring methods:STM, Topography, EFM, KPFM, SCM, PFM, CS-AFM, etc.

  • Possibility to carry out experiments in air, as well as in liquids and in controlled environment.

  • Investigation of small and big samples with ultra-high resolution (atomic-molecular level) and scanning range up to 100x100x10 µm.

  • Appications: Nanomaterials, Nanostructures, Biology and Biotechnology, Materials Science, Magnetic materials, Semiconductors, electric measurements, Polymers and Thin Organic Films, etc.


MST 4000A 4” PROBE STATION

​

  • Leakage Current ~100 fA, accompanied by Option for using Hot Chuck

  • Chuck: 4 Inch Low Noise Chuck , On Ceramic Pad, Vacuum Chuck On/off Switch, Chuck Ground, Back Gate

  • Magnification: 90x

  • Probe Tip: M5BG, HR : 0.5 x 30mm Gold Tungsten or Tungsten; M3BGHR : 0.5 x 30mm Gold Tungsten

MICROMED 3 LUM LED

​

  • MICROMED 3 LUM LED

  • The set includes 4 fluorescent blocks (UV, V, B, G)

  • Images of objects in the light of visible luminescence, as well as in transmitted light in a bright field

  • Both transmitted and reflected light are emitted from LEDs

  • Magnification of 40 and 100 times

POTENTIOSTAT - GALVANOSTAT R-45X

​

  • 9 current ranges

  • 4 potential ranges (± 1V, ± 2V, ± 5V, ± 12V)

  • IR - positive feedback compensation

  • Pulse modes 2 μs

  • Combined cell shutdown method - high-speed CMOS switch and electromagnetic relay

  • Current resolution up to 1 pA

  • Potential resolution up to 40 μV

  • Minimum recommended operating current 200 pA


S150-2 SPECTROMETER

​

  • High spectral resolution (up to 9 pm)

  • Measurement of shape and width of the spectral line

  • High accuracy of wavelength determination (up to 1 pm)

  • Long-term stability. Fixed position of optical elements, small size

  • Automatic wavelength calibration. High accuracy and reproducibility of measurement results for the entire instrument lifetime

  • Easy-to-use software, possibility to solve non-standard problems
